Blower for whirlpool bath applications. Available in different executions with several modular accessories, all in the same overall dimensions. Very small size, compact in shape, easy to install and with a very low noise.
|
Name |
Type |
P1 (kW) |
50/60Hz dual |
P heater (kW) |
Ozone rate (mg/h) |
DN |
|---|---|---|---|---|---|---|
|
BW |
1 ph |
0,8 |
- |
- |
- |
38mm |
|
BW-R (with heater element) |
1 ph |
1,1 |
- |
0,3 |
- |
38mm |
1ph 230V-50Hz
P = Pump absorbed
Characteristics
Insulation class F
Limit ambient temperature +40°C
Body material: black PPH
20 PPI open cell polyurethane foam
On request
Special voltages and frequencies.
Non-return valve VR (#288201).
|
Materials |
|
|---|---|
|
Body |
PPO |
|
Weight |
|
|---|---|
|
BW |
2,5kg |
|
BW-R |
2,6kg |
Dimension
Versions
Code 288901 - BLOWER BW 800 single phase 230V-50Hz, cable 2x1 length 1m AVAILABLE ON STOCK.
